BSV systems for operating rooms and medical areas
To protect patients, battery‑backed central power supply systems (BSV) must be used for surgical lights in operating rooms and other medically used areas. in the event of a failure or interruption of the general power supply (utility grid), the backup power network takes over with absolute reliability. afterwards, an emergency operating time of three hours, or one hour (if a second safety power source is available, e.g. diesel generator), must be ensured by the connected battery system. our production and all quality controls are carried out in accordance with ISO 9001:2000. the relevant regulations and requirements are defined in the following standards:
DIN VDE 0100-710, DIN VDE 0558-507, DIN EN 50171 (VDE 0558-508), DIN EN 50178 (VDE 0160), DIN EN 60076 (VDE 0532), DIN EN 60146 (VDE 0558), DIN EN 60601-2-41 (VDE 0750-2-4), DIN EN 61000-6-2 (VDE 0839-6-2) and 61000-6-3 (VDE 0839-6-3), DIN EN 61558-2-4 (VDE 0570-2-4)
In addition to the well‑known standard VDE 0100-710 (2012-11), the standard VDE 0558-507 (2008-12) defines the requirements for battery‑backed power supplies for medically used areas.
BSV systems according to this standard are intended to supply surgical lights (BSV 24V) and medical electrical devices (BSV 230V) with electrical energy for a limited time in the event of a failure or malfunction of the general power supply.
BSV systems in the online catalog
direct download
BSV 230V Kompakt
BSV 230 V COMPACT safety power supply system for medical loads in doctors’ practices, clinics and healthcare centers. Designed to provide reliable power to safety-critical medical applications during mains power failures. Compact system architecture with integrated monitoring and control technology.
BSV 230V MED
BSV 230 V MED medical safety power supply system for operating rooms and critical medical applications. Designed to ensure uninterrupted power supply for safety-relevant medical equipment. Flexible system architecture with building integration, remote monitoring and enhanced operational reliability for healthcare environments.
BSV 230V MPS
BSV 230 V MPS medical safety power supply system for operating rooms and critical medical applications requiring high availability. Designed for healthcare environments with demanding requirements for power continuity, system monitoring and operational reliability. Flexible configurations support a wide range of power capacities and application concepts.
BSV 230V SLC
BSV 230 V SLC safety power supply system for operating rooms and medical electrical loads. Designed to provide reliable power to critical healthcare applications with integrated monitoring and control technology. Suitable for a wide range of power requirements in medical facilities.
BSV 24V OP MPS
BSV 24 V OP MPS safety power supply system for operating lights in medical environments with high operational reliability. Designed for LED and halogen surgical luminaires with automatic bypass functionality and adjustable output voltage. Supports integration into modern building management and monitoring systems.
BSV 24V OP SLC
BSV 24 V OP SLC safety power supply system for operating lights in medical environments with precise voltage regulation. Designed for LED and halogen surgical luminaires and reliable illumination in operating theatres. Individually adjustable output voltage supports varying installation conditions and cable lengths.
Verteiler VIT-A
VIT-A distribution board for medical IT systems in operating rooms and Group 2 medical locations. Designed to provide safe power distribution for medical loads with integrated transfer switching and monitoring technology. Automatic source transfer, insulation monitoring and fault location support high operational reliability in critical healthcare environments.
Zubehör Tableau VIT-A
Für die komfortable Bedienung und Anzeige der elektrischen Komponenten innerhalb medizinisch genutzter Bereiche können verschiedene Meldesysteme zur Auswahl gestellt werden.Anzeige, Überwachung, Bedienung:· IT-Systeme· Versorgungssysteme für medizinische Gase· Batteriegestützte Stromversorgungssysteme (BSV)· Klima- und Belüftungssysteme· Raumbeleuchtungen· Kommunikationssysteme· OP-Tische sowie weitere Anlagen verschiedener Gewerke
Planungshandbuch BSV-Systeme
This planning manual is intended to support you in the design, planning and specification of battery-backed central power supply systems (BSV). Clearly and systematically structured into the following topic areas:- Fundamentals- Relevant Standards, Laws and Regulations- System Design, Planning and Installation Planning - Guide with a Practical Example Service, Testing and Maintenance- Additional Useful Information This manual covers, among others, the following standards (selection): DIN VDE 0100-710Low-voltage electrical installations in medical locationsDIN VDE 0558-507Battery-backed central power supply systems (BSV) for safety purposes supplying medical areasDIN EN IEC 62485-2Safety requirements for secondary batteries and battery installations – Stationary batteries
